Mustang Z54 Zero-Turn Rider

Item: 17AKFACW066
Mustang Z54 Zero-Turn Rider
Item: 17AKFACW066

Premium power, performance and reliable starting every time with Briggs & Stratton Professional Series engine. The large 54-in deck on the Mustang Z54 mows large area faster and moves easily across the yard with the support of two deck wheels and a front roller to smooth over bumps.

Documents and Guides
  • This item is currently not available
Sale Price
This item is currently unavailable on mtdparts.com

Features

Features

  • Briggs & Stratton Professional Series engine delivers premium power and performance
  • Heavy-duty, full length, fully welded, 2" tubular frame is designed to absorb impact, provide maximum stability and covered by a limited lifetime warranty
  • Large 54" steel cutting deck reduces mowing time in large areas and the anti-scalp deck wheels prevent turf damage and deliver a clean, even cut
  • Dual hydrostatic transmission delivers true zero turn performance for quicker mow times and improved maneuverability
  • Ride in more comfort and reduced vibration with the high-back seat and foam grip steering controls

Transmission

  • Hydro-Gear EZT 2200

Forward Speed

  • 7 MPH

Seat Type

  • 18" high back

Armrests

  • No

Anti-Scalping

  • Three gauge wheels

Deck Material

  • 12-gauge steel

Deck Lift

  • Foot pedal

Deck Engagement (PTO)

  • Electric

Reverse Speed

  • 2.5 MPH

Battery

  • 230 CCA

Headlight(s)

  • No

Cruise Control

  • No

Rear Tow Hitch

  • Yes

Specification

Engine

  • Engine Brand Briggs & Stratton
  • Engine Model Professional Series
  • Engine Model Number 44U877-0020
  • Engine Displacement 724cc
  • Engine Output 24HP
  • Starter Type Electric
  • Fuel Tank Capacity 3.5 gal. US (13.25 L)
  • Cylinders Twin
  • Engine Start Ignition Key
  • Engine Oil Capacity 2.0 qt. US (1.89 L)
  • Lubrication Fully pressurized
  • Charging System 12 amp regulated
  • Fuel Gauge No
  • Governor Mechanical
  • Choke Choke-a-matic
  • Air Filter Dual element
  • Oil Filter Yes
  • Fuel Delivery Carburetor

Battery

  • Battery 230 CCA
  • Battery Type Standard Lead-Acid
  • Battery Voltage 12V

Drive System

  • Transmission Hydro-Gear EZT 2200
  • Forward Speed 7 MPH
  • Reverse Speed 2.5 MPH
  • Drive System Hydrostatic

Cutting Deck

  • Deck Cutting Width 54 in
  • Deck Wash Yes
  • Deck Material 12-gauge steel
  • Deck Engagement (PTO) Electric
  • Deck Construction Stamped
  • Blade(s) Three
  • Deck Lift Foot pedal
  • Cutting Height Range 1'' - 4.5''
  • Anti-Scalping Three gauge wheels
  • Deck Positions 8

Chassis

  • Frame 2'' x 2'' tubular steel
  • Turning Radius 0°
  • ROPS No
  • Rear Tow Hitch Yes
  • Corrosion Protection Yes

Controls

  • Cruise Control No
  • Steering Control Lap Bars

Comfort

  • Seat Type 18" high back
  • Armrests No
  • Seat Adjustment Knob

Wheels

  • Rear Tires 20"x10"-8"
  • Front Tires 11"x6"-5"

Additional Specifications

  • Hour Meter Yes
  • Headlight(s) No
  • Cup Holder Yes
  • Operator Presence System Yes
  • Parking Brake Lap Bar Integrated
  • Model Number 17AKFACW066

Warranty

  • Residential Warranty 3-year limited residential
  • Frame Warranty Lifetime Limited
  • Deck Shell Warranty 3-year limited
  • Commercial Warranty No

Blade Specifications

  • Deck Cutting Width 54 in
